2 SDM Series

Taidi Corp offers a comprehensive range of deep well submersible pumps, from 2'' to 10'', perfect for drawing water from wells, ponds, lakes, and cisterns. The 2 SDM series is specifically designed for wells with a diameter of over 100mm, ensuring efficient and reliable water transfer. These pumps feature a durable construction, advanced technology, and are suitable for various applications including residential, agricultural, and industrial uses, providing consistent performance and longevity.

Specification

Output Diameter 2 Inch (50MM)
Suitable Well Diameter Minimum 2 inches (50mm)
Body Material Stainless Steel
Voltage 220V
Horse Power (HP) 0.25 - 0.5
Impeller 26 - 38
Weight (KG) 7 KG to 15 KG
Power Range 0.18 kW to 0.37 kW

Performance

Capacity (m³/jam) 1 cubic meters per hour (m³/hour)
Head Max Up to 35 meters
Operating Temperature Range 0°C to 40°C
Max Immersion Depth 35 meters
Sand Tolerance ≤ 0.25%
